Real-time Monitoring: Traditional solar street light requires workers to check the service conditions of the light on a regular basis. Real-time monitoring can be made for solar street light through computer platform at any time without dispatching personnel for onsite inspection. If the lighting-up time is insufficient, reasons can be analyzed according to practical conditions.
Controllable Lighting Time: Parameters of solar street light can be changed remotely; the maintenance team is not required to change the setting one by one on the site. Light Dimming: Energies stored in the battery and the load power determine the specific lighting time. Under the premise that the sunshine is insufficient, the lighting-up time can be effectively extended by regulating and controlling the brightness in different time periods during the night.
1. MPPT controller + Zigbee communication
.webp "物联网_(1).webp")
.webp "物联网_(2).webp")
2.Real-time Monitoring of Solar Street Light
1-On-line state
The light connected to the gateway will show green.
Otherwise it will turn grey/off-line.
2-Equipment state
The icon when the light is on will show green.
When the light is off, it will turn grey.
3-Alarm for checking
Off-line alarm and luminaire failure
4-Brightness
Setting of current brightness percentage.
5-Luminaire parameters
Data from MPPT Controller: System voltage, controller temperature, street light voltage, current, power, solar panel voltage, current, power and solar parameter settings.
3.Control Mode
1-Single light or gateway control, on/off control, dimming control
2-Gateway Group Control: Control the luminaires of the same group of gateways
Don’t change the setting without professional assistance. Parameters wrongly corrected may damage the equipment
